Made to Measure
Adapter Profile PVC/TK DECEUNINCK for BT 76
The blaugelb Adapter Profile PVC/TK made of a TK core (thermoplastic resin) and a two-sided 2 mm PVC top layer (polyvinyl chloride) offers the best possible heat and moisture protection on front and balcony doors made of plastic, aluminium, wood and wood/aluminium. The blaugelb Adapter Profile PVC/TK is sturdy, durable and is exceptionally quick and easy to fit. The blaugelb Adapter Profile PVC/TK enables thermal separation and reduces potential thermal bridges compared to conventional plastic profiles with steel reinforcement. It is dimensionally stable, 100 % free of HCFCs, HFCs and HBCDs.
The blaugelb Adapter Profile PVC/TK was specially developed for fitting as a floor recess profile under frames and system floor thresholds for floor-level elements. The milling contour of the blaugelb Adapter Profile PVC/TK is seamlessly adapted to both the system floor threshold profile as well as the window frame profile. A blaugelb Adapter Profile PVC/TK can thus be used for window frame systems and system floor thresholds from a profile system provider. The profile-specific Adapter Profiles PVC/TK can be produced at heights of 30 to 300 mm.
By virtue of the innovative dovetail joint, the blaugelb Adapter Profiles PVC/TK can be positively interlocked to create any desired length. The dovetail joint optimises waste, in some cases avoiding waste altogether.
Due to the milled tongue and groove joint, it is possible to adapt the profile-specific Adapter Profile PVC/TK with profile-independent plinth thermal insulation profiles. The profiles which are to be joined have a groove on one edge and a tongue on the other edge and can be coupled in height one under the other.
The contoured mount guarantees quick and easy installation of the profile with the blaugelb Frame Screw Fix FK-T30 and precise positioning thanks to the contour cutting. This prevents the formation of a hollow chamber between the adapter profile and the frame, and airtightness is achieved thanks to the process-safe sealing.
- effective insulation offering high potential savings
- can be combined with universal Plinth Thermal Insulation Profile EPS and PVC/TK
- effective insulation offering high potential savings
- permanently eliminates energy weak points on components installed on floor slabs and enhances indoor comfort
- prevents damage caused by moisture and mould
- high load transfer, low weight
- force-locking screwing in the frame/threshold structure
- recyclable, UV-resistant
- tested to be very low in emissions according to EMICODE® EC1 Plus
| Surface and top layer: | On both sides 2 mm PVC white |
| Material: | Thermoplastic resin (TK) |
| Compressive load bearing capacity at 60 x 40 mm: (blaugelb Spacer Block) | 4,440 N |
| Compressive load bearing capacity at 170 x 53 mm: (blaugelb Shim Block HST) | 16,669 N |
| Compressive load bearing capacity at 210 x 53 mm: (blaugelb Shim Block HST) | 20,628 N |
| Thermal transmittance value U-value at 55 mm: | 0.696 W/m²K |
| Thermal transmittance value U-value at 60 mm: | 0.641 W/m²K |
| Dimensional stability: | Very high, including outdoor weathering |
| Water absorption after 28 days under water: DIN 12087 | ≤ 0.5 vol. % |
| Screw withdrawal values: blaugelb Frame Screw Fix FK-T30 7.5 x L mm 60 mm screw-in depth | X-axis: FRK 4.06 kN Y-axis: FRK 3.67 kN |
| UV-resistance of the PVC top layer: DIN EN 513 (irradiation energy 12 GJ/m² or outdoor weathering over 5 years) | Fastness to weathering and light: no colour variations occur that exceed grey scale grade 4 according to ISO 105-A03 |
| Waste code: | AVV 070213 |
The information provided in this document corresponds to the information and technical details available to the best of our knowledge. However, this does not constitute a guarantee pursuant to section 443 of the German Civil Code (BGB). Our processing instructions are to be considered only as general guidelines and may differ in the individual case due to the range of possible uses and applications. They do therefore not automatically exempt the user from carrying out their own tests. We reserve the right to make technical modifications and enhancements at any time.
| Product name | PU | Item no. |
|---|---|---|
blaugelb Adapter Profile PVC/TK 55 x 30 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007904 |
blaugelb Adapter Profile PVC/TK 55 x 30 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007919 |
blaugelb Adapter Profile PVC/TK 55 x 40 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007905 |
blaugelb Adapter Profile PVC/TK 55 x 40 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007920 |
blaugelb Adapter Profile PVC/TK 55 x 50 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007906 |
blaugelb Adapter Profile PVC/TK 55 x 50 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007921 |
blaugelb Adapter Profile PVC/TK 55 x 80 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007907 |
blaugelb Adapter Profile PVC/TK 55 x 80 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007922 |
blaugelb Adapter Profile PVC/TK 55 x 100 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007908 |
blaugelb Adapter Profile PVC/TK 55 x 100 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007923 |
blaugelb Adapter Profile PVC/TK 55 x 130 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007909 |
blaugelb Adapter Profile PVC/TK 55 x 130 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007924 |
blaugelb Adapter Profile PVC/TK 55 x 150 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007910 |
blaugelb Adapter Profile PVC/TK 55 x 150 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007925 |
blaugelb Adapter Profile PVC/TK 55 x 160 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007911 |
blaugelb Adapter Profile PVC/TK 55 x 160 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007926 |
blaugelb Adapter Profile PVC/TK 55 x 180 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007912 |
blaugelb Adapter Profile PVC/TK 55 x 180 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007927 |
blaugelb Adapter Profile PVC/TK 55 x 200 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007913 |
blaugelb Adapter Profile PVC/TK 55 x 200 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007928 |
blaugelb Adapter Profile PVC/TK 55 x 220 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007914 |
blaugelb Adapter Profile PVC/TK 55 x 220 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007929 |
blaugelb Adapter Profile PVC/TK 55 x 240 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007915 |
blaugelb Adapter Profile PVC/TK 55 x 240 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007930 |
blaugelb Adapter Profile PVC/TK 55 x 260 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007916 |
blaugelb Adapter Profile PVC/TK 55 x 260 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007931 |
blaugelb Adapter Profile PVC/TK 55 x 280 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007917 |
blaugelb Adapter Profile PVC/TK 55 x 280 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007932 |
blaugelb Adapter Profile PVC/TK 55 x 300 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007918 |
blaugelb Adapter Profile PVC/TK 55 x 300 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007933 |
blaugelb Adapter Profile PVC/TK 60 x 30 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100003008 |
blaugelb Adapter Profile PVC/TK 60 x 30 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100003010 |
blaugelb Adapter Profile PVC/TK 60 x 40 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100003384 |
blaugelb Adapter Profile PVC/TK 60 x 40 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100003391 |
blaugelb Adapter Profile PVC/TK 60 x 50 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100003009 |
blaugelb Adapter Profile PVC/TK 60 x 50 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100003011 |
blaugelb Adapter Profile PVC/TK 60 x 80 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100003385 |
blaugelb Adapter Profile PVC/TK 60 x 80 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100003392 |
blaugelb Adapter Profile PVC/TK 60 x 100 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100003386 |
blaugelb Adapter Profile PVC/TK 60 x 100 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100003393 |
blaugelb Adapter Profile PVC/TK 60 x 130 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100003387 |
blaugelb Adapter Profile PVC/TK 60 x 130 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100003394 |
blaugelb Adapter Profile PVC/TK 60 x 150 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100003388 |
blaugelb Adapter Profile PVC/TK 60 x 150 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100003395 |
blaugelb Adapter Profile PVC/TK 60 x 160 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100003389 |
blaugelb Adapter Profile PVC/TK 60 x 160 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100003396 |
blaugelb Adapter Profile PVC/TK 60 x 180 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100003390 |
blaugelb Adapter Profile PVC/TK 60 x 180 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100003740 |
blaugelb Adapter Profile PVC/TK 60 x 200 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007934 |
blaugelb Adapter Profile PVC/TK 60 x 200 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007940 |
blaugelb Adapter Profile PVC/TK 60 x 220 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007935 |
blaugelb Adapter Profile PVC/TK 60 x 220 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007941 |
blaugelb Adapter Profile PVC/TK 60 x 240 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007936 |
blaugelb Adapter Profile PVC/TK 60 x 240 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007942 |
blaugelb Adapter Profile PVC/TK 60 x 260 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007937 |
blaugelb Adapter Profile PVC/TK 60 x 260 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007943 |
blaugelb Adapter Profile PVC/TK 60 x 280 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007938 |
blaugelb Adapter Profile PVC/TK 60 x 280 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007944 |
blaugelb Adapter Profile PVC/TK 60 x 300 x 3000 mm DECEUNINCK for BT 76 | 1 piece | 3100007939 |
blaugelb Adapter Profile PVC/TK 60 x 300 x 4000 mm DECEUNINCK for BT 76 | 1 piece | 3100007945 |
