Adapter Profile PVC/TK VEKA for BT 76

The blaugelb Adapter Profile PVC/TK made of a TK core (thermoplastic resin) and a two-sided 2 mm PVC top layer (polyvinyl chloride) offers the best possible heat and moisture protection on front and balcony doors made of plastic, aluminium, wood and wood/aluminium. The blaugelb Adapter Profile PVC/TK is sturdy, durable and is exceptionally quick and easy to fit. The blaugelb Adapter Profile PVC/TK enables thermal separation and reduces potential thermal bridges compared to conventional plastic profiles with steel reinforcement. It is dimensionally stable, 100 % free of HCFCs, HFCs and HBCDs.

The blaugelb Adapter Profile PVC/TK was specially developed for fitting as a floor recess profile under frames and system floor thresholds for floor-level elements. The milling contour of the blaugelb Adapter Profile PVC/TK is seamlessly adapted to both the system floor threshold profile as well as the window frame profile. A blaugelb Adapter Profile PVC/TK can thus be used for window frame systems and system floor thresholds from a profile system provider. The profile-specific Adapter Profiles PVC/TK can be produced at heights of 30 to 300 mm.

By virtue of the innovative dovetail joint, the blaugelb Adapter Profiles PVC/TK can be positively interlocked to create any desired length. The dovetail joint optimises waste, in some cases avoiding waste altogether.

Due to the milled tongue and groove joint, it is possible to adapt the profile-specific Adapter Profile PVC/TK with profile-independent plinth thermal insulation profiles. The profiles which are to be joined have a groove on one edge and a tongue on the other edge and can be coupled in height one under the other.

The contoured mount guarantees quick and easy installation of the profile mwith the blaugelb Frame Screw Fix FK-T30 and precise positioning thanks to the contour cutting. This prevents the formation of a hollow chamber between the adapter profile and the frame, and airtightness is achieved thanks to the process-safe sealing.

  • effective insulation offering high potential savings
  • can be combined with universal Plinth Thermal Insulation Profile EPS und PVC/TK
  • permanently eliminates energy weak points on components installed on floor slabs and enhances indoor comfort
  • prevents damage caused by moisture and mould
  • high load transfer, low weight
  • force-locking screwing in the frame/threshold structure
  • recyclable, UV-resistant
  • tested to be very low in emissions according to EMICODE® EC1 Plus

Surface and top layer:On both sides 2 mm PVC white
Material:Thermoplastic resin (TK)
Compressive load bearing capacity at 60 x 40 mm:
(blaugelb Spacer Block)		4,440 N
Compressive load bearing capacity at 170 x 53 mm:
(blaugelb Shim Block HST)		16,669 N
Compressive load bearing capacity at 210 x 53 mm:
(blaugelb Shim Block HST)		20,628 N
Thermal transmittance value U-value at 55 mm:0.696 W/m²K
Thermal transmittance value U-value at 60 mm:0.641 W/m²K
Thermal transmittance value U-value at 66 mm:0.586 W/m²K
Thermal transmittance value U-value at 76 mm:0.509 W/m²K
Dimensional stability:Very high, including outdoor weathering
Water absorption after 28 days under water:
DIN 12087		≤ 0.5 vol. %
Screw withdrawal values:
blaugelb Frame Screw Fix FK-T30 7.5 x L mm
60 mm screw-in depth
X-axis: FRK 4.06 kN
Y-axis: FRK 3.67 kN
UV-resistance of the PVC top layer:
DIN EN 513
(irradiation energy 12 GJ/m² or outdoor weathering over 5 years)		Fastness to weathering and light:
No colour variations occur that exceed grey scale grade 4 according to ISO 105-A03
Waste code:AVV 070213

The information provided in this document corresponds to the information and technical details available to the best of our knowledge. However, this does not constitute a guarantee pursuant to section 443 of the German Civil Code (BGB). Our processing instructions are to be considered only as general guidelines and may differ in the individual case due to the range of possible uses and applications. They do therefore not automatically exempt the user from carrying out their own tests. We reserve the right to make technical modifications and enhancements at any time.

Your product

Your profile system

Softline 76
EditTo top

Your product

Adapter Profile PVC/TK VEKA for BT 76
EditTo top

Product namePUItem no.

blaugelb Adapter Profile PVC/TK 55 x 30 x 3000 mm

VEKA for BT 76

1 piece3100004583

blaugelb Adapter Profile PVC/TK 55 x 30 x 4000 mm

VEKA for BT 76

1 piece3100004592

blaugelb Adapter Profile PVC/TK 55 x 40 x 3000 mm

VEKA for BT 76

1 piece3100004584

blaugelb Adapter Profile PVC/TK 55 x 40 x 4000 mm

VEKA for BT 76

1 piece3100004593

blaugelb Adapter Profile PVC/TK 55 x 50 x 3000 mm

VEKA for BT 76

1 piece3100004585

blaugelb Adapter Profile PVC/TK 55 x 50 x 4000 mm

VEKA for BT 76

1 piece3100004594

blaugelb Adapter Profile PVC/TK 55 x 80 x 3000 mm

VEKA for BT 76

1 piece3100004586

blaugelb Adapter Profile PVC/TK 55 x 80 x 4000 mm

VEKA for BT 76

1 piece3100004595

blaugelb Adapter Profile PVC/TK 55 x 100 x 3000 mm

VEKA for BT 76

1 piece3100004587

blaugelb Adapter Profile PVC/TK 55 x 100 x 4000 mm

VEKA for BT 76

1 piece3100004596

blaugelb Adapter Profile PVC/TK 55 x 130 x 3000 mm

VEKA for BT 76

1 piece3100004588

blaugelb Adapter Profile PVC/TK 55 x 130 x 4000 mm

VEKA for BT 76

1 piece3100004597

blaugelb Adapter Profile PVC/TK 55 x 150 x 3000 mm

VEKA for BT 76

1 piece3100004589

blaugelb Adapter Profile PVC/TK 55 x 150 x 4000 mm

VEKA for BT 76

1 piece3100004598

blaugelb Adapter Profile PVC/TK 55 x 160 x 3000 mm

VEKA for BT 76

1 piece3100004590

blaugelb Adapter Profile PVC/TK 55 x 160 x 4000 mm

VEKA for BT 76

1 piece3100004599

blaugelb Adapter Profile PVC/TK 55 x 180 x 3000 mm

VEKA for BT 76

1 piece3100004591

blaugelb Adapter Profile PVC/TK 55 x 180 x 4000 mm

VEKA for BT 76

1 piece3100004600

blaugelb Adapter Profile PVC/TK 55 x 200 x 3000 mm

VEKA for BT 76

1 piece3100004914

blaugelb Adapter Profile PVC/TK 55 x 200 x 4000 mm

VEKA for BT 76

1 piece3100004920

blaugelb Adapter Profile PVC/TK 55 x 220 x 3000 mm

VEKA for BT 76

1 piece3100004915

blaugelb Adapter Profile PVC/TK 55 x 220 x 4000 mm

VEKA for BT 76

1 piece3100004921

blaugelb Adapter Profile PVC/TK 55 x 240 x 3000 mm

VEKA for BT 76

1 piece3100004916

blaugelb Adapter Profile PVC/TK 55 x 240 x 4000 mm

VEKA for BT 76

1 piece3100004922

blaugelb Adapter Profile PVC/TK 55 x 260 x 3000 mm

VEKA for BT 76

1 piece3100004917

blaugelb Adapter Profile PVC/TK 55 x 260 x 4000 mm

VEKA for BT 76

1 piece3100004923

blaugelb Adapter Profile PVC/TK 55 x 280 x 3000 mm

VEKA for BT 76

1 piece3100004918

blaugelb Adapter Profile PVC/TK 55 x 280 x 4000 mm

VEKA for BT 76

1 piece3100004924

blaugelb Adapter Profile PVC/TK 55 x 300 x 3000 mm

VEKA for BT 76

1 piece3100004919

blaugelb Adapter Profile PVC/TK 55 x 300 x 4000 mm

VEKA for BT 76

1 piece3100004925


blaugelb Adapter Profile PVC/TK 60 x 30 x 3000 mm

VEKA for BT 76

1 piece3100003052

blaugelb Adapter Profile PVC/TK 60 x 30 x 4000 mm

VEKA for BT 76

1 piece3100003054

blaugelb Adapter Profile PVC/TK 60 x 40 x 3000 mm

VEKA for BT 76

1 piece3100003509

blaugelb Adapter Profile PVC/TK 60 x 40 x 4000 mm

VEKA for BT 76

1 piece3100003516

blaugelb Adapter Profile PVC/TK 60 x 50 x 3000 mm

VEKA for BT 76

1 piece3100003053

blaugelb Adapter Profile PVC/TK 60 x 50 x 4000 mm

VEKA for BT 76

1 piece3100003055

blaugelb Adapter Profile PVC/TK 60 x 80 x 3000 mm

VEKA for BT 76

1 piece3100003510

blaugelb Adapter Profile PVC/TK 60 x 80 x 4000 mm

VEKA for BT 76

1 piece3100003517

blaugelb Adapter Profile PVC/TK 60 x 100 x 3000 mm

VEKA for BT 76

1 piece3100003511

blaugelb Adapter Profile PVC/TK 60 x 100 x 4000 mm

VEKA for BT 76

1 piece3100003518

blaugelb Adapter Profile PVC/TK 60 x 130 x 3000 mm

VEKA for BT 76

1 piece3100003512

blaugelb Adapter Profile PVC/TK 60 x 130 x 4000 mm

VEKA for BT 76

1 piece3100003519

blaugelb Adapter Profile PVC/TK 60 x 150 x 3000 mm

VEKA for BT 76

1 piece3100003513

blaugelb Adapter Profile PVC/TK 60 x 150 x 4000 mm

VEKA for BT 76

1 piece3100003520

blaugelb Adapter Profile PVC/TK 60 x 160 x 3000 mm

VEKA for BT 76

1 piece3100003514

blaugelb Adapter Profile PVC/TK 60 x 160 x 4000 mm

VEKA for BT 76

1 piece3100003521

blaugelb Adapter Profile PVC/TK 60 x 180 x 3000 mm

VEKA for BT 76

1 piece3100003515

blaugelb Adapter Profile PVC/TK 60 x 180 x 4000 mm

VEKA for BT 76

1 piece3100003522

blaugelb Adapter Profile PVC/TK 60 x 200 x 3000 mm

VEKA for BT 76

1 piece3100004926

blaugelb Adapter Profile PVC/TK 60 x 200 x 4000 mm

VEKA for BT 76

1 piece3100005178

blaugelb Adapter Profile PVC/TK 60 x 220 x 3000 mm

VEKA for BT 76

1 piece3100004927

blaugelb Adapter Profile PVC/TK 60 x 220 x 4000 mm

VEKA for BT 76

1 piece3100005179

blaugelb Adapter Profile PVC/TK 60 x 240 x 3000 mm

VEKA for BT 76

1 piece3100004928

blaugelb Adapter Profile PVC/TK 60 x 240 x 4000 mm

VEKA for BT 76

1 piece3100005180

blaugelb Adapter Profile PVC/TK 60 x 260 x 3000 mm

VEKA for BT 76

1 piece3100004929

blaugelb Adapter Profile PVC/TK 60 x 260 x 4000 mm

VEKA for BT 76

1 piece3100005181

blaugelb Adapter Profile PVC/TK 60 x 280 x 3000 mm

VEKA for BT 76

1 piece3100004930

blaugelb Adapter Profile PVC/TK 60 x 280 x 4000 mm

VEKA for BT 76

1 piece3100005182

blaugelb Adapter Profile PVC/TK 60 x 300 x 3000 mm

VEKA for BT 76

1 piece3100004931

blaugelb Adapter Profile PVC/TK 60 x 300 x 4000 mm

VEKA for BT 76

1 piece3100005183


blaugelb Adapter Profile PVC/TK 66 x 30 x 3000 mm

VEKA for BT 76

1 piece3100011010

blaugelb Adapter Profile PVC/TK 66 x 30 x 4000 mm

VEKA for BT 76

1 piece3100011025

blaugelb Adapter Profile PVC/TK 66 x 40 x 3000 mm

VEKA for BT 76

1 piece3100011011

blaugelb Adapter Profile PVC/TK 66 x 40 x 4000 mm

VEKA for BT 76

1 piece3100011026

blaugelb Adapter Profile PVC/TK 66 x 50 x 3000 mm

VEKA for BT 76

1 piece3100011012

blaugelb Adapter Profile PVC/TK 66 x 50 x 4000 mm

VEKA for BT 76

1 piece3100011027

blaugelb Adapter Profile PVC/TK 66 x 80 x 3000 mm

VEKA for BT 76

1 piece3100011013

blaugelb Adapter Profile PVC/TK 66 x 80 x 4000 mm

VEKA for BT 76

1 piece3100011028

blaugelb Adapter Profile PVC/TK 66 x 100 x 3000 mm

VEKA for BT 76

1 piece3100011014

blaugelb Adapter Profile PVC/TK 66 x 100 x 4000 mm

VEKA for BT 76

1 piece3100011029

blaugelb Adapter Profile PVC/TK 66 x 130 x 3000 mm

VEKA for BT 76

1 piece3100011015

blaugelb Adapter Profile PVC/TK 66 x 130 x 4000 mm

VEKA for BT 76

1 piece3100011030

blaugelb Adapter Profile PVC/TK 66 x 150 x 3000 mm

VEKA for BT 76

1 piece3100011016

blaugelb Adapter Profile PVC/TK 66 x 150 x 4000 mm

VEKA for BT 76

1 piece3100011031

blaugelb Adapter Profile PVC/TK 66 x 160 x 3000 mm

VEKA for BT 76

1 piece3100011017

blaugelb Adapter Profile PVC/TK 66 x 160 x 4000 mm

VEKA for BT 76

1 piece3100011032

blaugelb Adapter Profile PVC/TK 66 x 180 x 3000 mm

VEKA for BT 76

1 piece3100011018

blaugelb Adapter Profile PVC/TK 66 x 180 x 4000 mm

VEKA for BT 76

1 piece3100011033

blaugelb Adapter Profile PVC/TK 66 x 200 x 3000 mm

VEKA for BT 76

1 piece3100011019

blaugelb Adapter Profile PVC/TK 66 x 200 x 4000 mm

VEKA for BT 76

1 piece3100011034

blaugelb Adapter Profile PVC/TK 66 x 220 x 3000 mm

VEKA for BT 76

1 piece3100011020

blaugelb Adapter Profile PVC/TK 66 x 220 x 4000 mm

VEKA for BT 76

1 piece3100011035

blaugelb Adapter Profile PVC/TK 66 x 240 x 3000 mm

VEKA for BT 76

1 piece3100011021

blaugelb Adapter Profile PVC/TK 66 x 240 x 4000 mm

VEKA for BT 76

1 piece3100011036

blaugelb Adapter Profile PVC/TK 66 x 260 x 3000 mm

VEKA for BT 76

1 piece3100011022

blaugelb Adapter Profile PVC/TK 66 x 260 x 4000 mm

VEKA for BT 76

1 piece3100011037

blaugelb Adapter Profile PVC/TK 66 x 280 x 3000 mm

VEKA for BT 76

1 piece3100011023

blaugelb Adapter Profile PVC/TK 66 x 280 x 4000 mm

VEKA for BT 76

1 piece3100011038

blaugelb Adapter Profile PVC/TK 66 x 300 x 3000 mm

VEKA for BT 76

1 piece3100011024

blaugelb Adapter Profile PVC/TK 66 x 300 x 4000 mm

VEKA for BT 76

1 piece3100011039


blaugelb Adapter Profile PVC/TK 76 x 30 x 3000 mm

VEKA for BT 76

1 piece3100013249

blaugelb Adapter Profile PVC/TK 76 x 30 x 4000 mm

VEKA for BT 76

1 piece3100013264

blaugelb Adapter Profile PVC/TK 76 x 40 x 3000 mm

VEKA for BT 76

1 piece3100013250

blaugelb Adapter Profile PVC/TK 76 x 40 x 4000 mm

VEKA for BT 76

1 piece3100013265

blaugelb Adapter Profile PVC/TK 76 x 50 x 3000 mm

VEKA for BT 76

1 piece3100013251

blaugelb Adapter Profile PVC/TK 76 x 50 x 4000 mm

VEKA for BT 76

1 piece3100013266

blaugelb Adapter Profile PVC/TK 76 x 80 x 3000 mm

VEKA for BT 76

1 piece3100013252

blaugelb Adapter Profile PVC/TK 76 x 80 x 4000 mm

VEKA for BT 76

1 piece3100013267

blaugelb Adapter Profile PVC/TK 76 x 100 x 3000 mm

VEKA for BT 76

1 piece3100013253

blaugelb Adapter Profile PVC/TK 76 x 100 x 4000 mm

VEKA for BT 76

1 piece3100013268

blaugelb Adapter Profile PVC/TK 76 x 130 x 3000 mm

VEKA for BT 76

1 piece3100013254

blaugelb Adapter Profile PVC/TK 76 x 130 x 4000 mm

VEKA for BT 76

1 piece3100013269

blaugelb Adapter Profile PVC/TK 76 x 150 x 3000 mm

VEKA for BT 76

1 piece3100013255

blaugelb Adapter Profile PVC/TK 76 x 150 x 4000 mm

VEKA for BT 76

1 piece3100013270

blaugelb Adapter Profile PVC/TK 76 x 160 x 3000 mm

VEKA for BT 76

1 piece3100013256

blaugelb Adapter Profile PVC/TK 76 x 160 x 4000 mm

VEKA for BT 76

1 piece3100013271

blaugelb Adapter Profile PVC/TK 76 x 180 x 3000 mm

VEKA for BT 76

1 piece3100013257

blaugelb Adapter Profile PVC/TK 76 x 180 x 4000 mm

VEKA for BT 76

1 piece3100013272

blaugelb Adapter Profile PVC/TK 76 x 200 x 3000 mm

VEKA for BT 76

1 piece3100013258

blaugelb Adapter Profile PVC/TK 76 x 200 x 4000 mm

VEKA for BT 76

1 piece3100013273

blaugelb Adapter Profile PVC/TK 76 x 220 x 3000 mm

VEKA for BT 76

1 piece3100013259

blaugelb Adapter Profile PVC/TK 76 x 220 x 4000 mm

VEKA for BT 76

1 piece3100013274

blaugelb Adapter Profile PVC/TK 76 x 240 x 3000 mm

VEKA for BT 76

1 piece3100013260

blaugelb Adapter Profile PVC/TK 76 x 240 x 4000 mm

VEKA for BT 76

1 piece3100013275

blaugelb Adapter Profile PVC/TK 76 x 260 x 3000 mm

VEKA for BT 76

1 piece3100013261

blaugelb Adapter Profile PVC/TK 76 x 260 x 4000 mm

VEKA for BT 76

1 piece3100013276

blaugelb Adapter Profile PVC/TK 76 x 280 x 3000 mm

VEKA for BT 76

1 piece3100013262

blaugelb Adapter Profile PVC/TK 76 x 280 x 4000 mm

VEKA for BT 76

1 piece3100013277

blaugelb Adapter Profile PVC/TK 76 x 300 x 3000 mm

VEKA for BT 76

1 piece3100013263

blaugelb Adapter Profile PVC/TK 76 x 300 x 4000 mm

VEKA for BT 76

1 piece3100013278

DE EN

DE

DE EN

DE

Discover our solutions



How can we help you?

We would be glad to assist you in your concerns – contact us.

Contact us
