Made to Measure
Frame Extension PVC/TK DECEUNINCK for BT 84
The blaugelb Frame Extension PVC/TK 30 dB with sound and thermal insulation properties was specially developed for installation as an extension of the frame on windows and doors made of plastic for renovation as well as new construction. It consists of a layer structure with a core made of engineering-grade plastic (TK) in the anchoring plane as well as two insulating layers made of rigid polystyrene foam on the sides that are enclosed by two PVC surface layers adapted to the white tone of the frame profile. The use of this special layer structure results in a force-locking connection with the frame, an outstanding thermal insulation as well as good sound insulation properties.
The frame extension is designed for optimum and quick installation thanks to its resilience and its low weight. Thanks to the profile-specific contour, the frame extension adapts seamlessly to the existing window or door profile and ensures the perfect transition between the profiles. Thermal insulation is thus achieved without the generation of an additional thermal bridge, e.g. due to a steel core.
The contoured mount guarantees quick and easy installation of the profile with the blaugelb Frame Screw Fix FK-T30 and precise positioning thanks to the contour cutting. This prevents the formation of a hollow chamber between the frame extension and the frame, and airtightness is achieved thanks to the process-safe sealing.
The product range is available in ready lengths of 1,500, 2,500 and 3,000 mm.
- effective insulation offering high potential savings
- permanently eliminates energy weak points on components and increases the sound insulation and indoor comfort
- screw connection through the dowel hole bore 8 mm
- PVC surface layer matched to the white tone of the profile
- defined sealing between frame and frame extension for maintaining airtightness
- low weight
- dimensionally stable, 100 % free of HCFCs, HFCs and HBCDs
- UV-resistant PVC top layer
- tested to be very low in emissions according to EMICODE® EC1 Plus
| Surface and top layer: | On both sides 2 mm PVC white |
| Material: | Rigid polystyrene foam (XPS) Core made of thermoplastic resin (TK) |
| Thermal transmittance value U-value at 85 mm 30 dB: | 0.389 W/m²K |
| Water vapour diffusion resistance: DIN 4108-3:2018 | Vapour-retardant |
| Airborne sound insulation: DIN EN ISO 717-1 | Without sound insulation membrane: Rw 30.0 dB ± 1.2 dB |
| Dimensional stability: | Very high, including outdoor weathering |
| Water absorption after 28 days under water: DIN 12087 | ≤ 0.5 vol. % |
| Screw withdrawal values: blaugelb Frame Screw Fix FK-T30 7.5 x L mm 60 mm screw-in depth | X-axis: FRK 1.77 kN Y-axis: FRK 3.06 kN |
| UV-resistance of the PVC top layer: DIN EN 513 (irradiation energy 12 GJ/m² or outdoor weathering over 5 years) | Fastness to weathering and light: No colour variations occur that exceed grey scale grade 4 according to ISO 105-A03 |
| Waste code: | AVV 070213 |
The information provided in this document corresponds to the information and technical details available to the best of our knowledge. However, this does not constitute a guarantee pursuant to section 443 of the German Civil Code (BGB). Our processing instructions are to be considered only as general guidelines and may differ in the individual case due to the range of possible uses and applications. They do therefore not automatically exempt the user from carrying out their own tests. We reserve the right to make technical modifications and enhancements at any time.
| Product name | PU | Item no. |
|---|---|---|
blaugelb Frame Extension PVC/TK 84 x 50 x 1500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002467 |
blaugelb Frame Extension PVC/TK 84 x 50 x 2500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002128 |
blaugelb Frame Extension PVC/TK 84 x 50 x 3000 30 dB DECEUNINCK for BT 84 | 1 piece | 3100001785 |
blaugelb Frame Extension PVC/TK 84 x 75 x 1500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002468 |
blaugelb Frame Extension PVC/TK 84 x 75 x 2500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002129 |
blaugelb Frame Extension PVC/TK 84 x 75 x 3000 30 dB DECEUNINCK for BT 84 | 1 piece | 3100001786 |
blaugelb Frame Extension PVC/TK 84 x 100 x 1500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002469 |
blaugelb Frame Extension PVC/TK 84 x 100 x 2500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002130 |
blaugelb Frame Extension PVC/TK 84 x 100 x 3000 30 dB DECEUNINCK for BT 84 | 1 piece | 3100001787 |
blaugelb Frame Extension PVC/TK 84 x 125 x 1500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002470 |
blaugelb Frame Extension PVC/TK 84 x 125 x 2500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002131 |
blaugelb Frame Extension PVC/TK 84 x 125 x 3000 30 dB DECEUNINCK for BT 84 | 1 piece | 3100001788 |
blaugelb Frame Extension PVC/TK 84 x 150 x 1500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002471 |
blaugelb Frame Extension PVC/TK 84 x 150 x 2500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002132 |
blaugelb Frame Extension PVC/TK 84 x 150 x 3000 30 dB DECEUNINCK for BT 84 | 1 piece | 3100001789 |
blaugelb Frame Extension PVC/TK 84 x 175 x 1500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002472 |
blaugelb Frame Extension PVC/TK 84 x 175 x 2500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002133 |
blaugelb Frame Extension PVC/TK 84 x 175 x 3000 30 dB DECEUNINCK for BT 84 | 1 piece | 3100001790 |
blaugelb Frame Extension PVC/TK 84 x 200 x 1500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002473 |
blaugelb Frame Extension PVC/TK 84 x 200 x 2500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002134 |
blaugelb Frame Extension PVC/TK 84 x 200 x 3000 30 dB DECEUNINCK for BT 84 | 1 piece | 3100001791 |
blaugelb Frame Extension PVC/TK 84 x 225 x 1500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002474 |
blaugelb Frame Extension PVC/TK 84 x 225 x 2500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002135 |
blaugelb Frame Extension PVC/TK 84 x 225 x 3000 30 dB DECEUNINCK for BT 84 | 1 piece | 3100001792 |
blaugelb Frame Extension PVC/TK 84 x 250 x 1500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002475 |
blaugelb Frame Extension PVC/TK 84 x 250 x 2500 30 dB DECEUNINCK for BT 84 | 1 piece | 3100002136 |
blaugelb Frame Extension PVC/TK 84 x 250 x 3000 30 dB DECEUNINCK for BT 84 | 1 piece | 3100001793 |
