Plinth Thermal Insulation Profile PVC/TK DECEUNINCK for BT 76

The blaugelb Plinth Thermal Insulation Profile PVC/TK made of a TK core (thermoplastic resin) and a two-sided 2 mm PVC top layer (polyvinyl chloride) offers the best possible heat and moisture protection on balcony doors made of plastic, aluminium, wood and wood/aluminium. The blaugelb Plinth Thermal Insulation Profile PVC/TK is sturdy, durable and is exceptionally quick and easy to fit. The blaugelb Plinth Thermal Insulation Profile PVC/TK enables thermal separation and reduces potential thermal bridges compared to conventional plastic profiles with steel reinforcement. It is dimensionally stable, 100 % free of HCFCs, HFCs and HBCDs.

The blaugelb Plinth Thermal Insulation Profile PVC/TK was specially developed for fitting as a floor recess profile under frames for floor-level elements. The profile-specific Plinth Thermal Insulation Profiles PVC/TK can be produced at heights of 30 to 300 mm. By virtue of the innovative dovetail joint, the blaugelb Plinth Thermal Insulation Profiles PVC/TK can be positively interlocked to create any desired length. The dovetail joint optimises waste, in some cases avoiding waste altogether.

Due to the milled tongue and groove joint, it is possible to adapt the profile-specific Plinth Thermal Insulation Profile PVC/TK with profile-independent plinth thermal insulation profiles. The profiles which are to be joined have a groove on one edge and a tongue on the other edge and can be coupled in height one under the other. The contoured mount guarantees quick and easy installation of the profile with the blaugelb Frame Screw Fix FK-T30 and precise positioning thanks to the contour cutting. This prevents the formation of a hollow chamber between the plinth thermal insulation profile and the frame, and airtightness is achieved thanks to the process-safe sealing.

  • effective insulation offering high potential savings
  • permanently eliminates energy weak points on components
    installed on floor slabs and enhances indoor comfort
  • prevents damage caused by moisture and mould
  • high load transfer, low weight
  • force-locking screwing in the frame structure
  • UV-resistant PVC top layer
  • tested to be very low in emissions according to EMICODE® EC1 Plus

Surface and top layer:On both sides 2 mm PVC white
Material:Thermoplastic resin (TK)
Compressive load bearing capacity at 60 x 40 mm:
(blaugelb Spacer Block)		4,440 N
Compressive load bearing capacity at 170 x 53 mm:
(blaugelb Shim Block HST)		16,669 N
Compressive load bearing capacity at 210 x 53 mm:
(blaugelb Shim Block HST)		20,628 N
Fire behaviour:
DIN 4102-1:1998-05		B2
Fire behaviour:
DIN EN 13501-1:2019-05		CLASS E
Thermal transmittance value U-value at 55 mm:0.696 W/m²K
Thermal transmittance value U-value at 60 mm:0.641 W/m²K
Dimensional stability:Very high, including outdoor weathering
Water absorption after 28 days under water:
DIN 12087		≤ 0.5 vol. %
Screw withdrawal values:
blaugelb Frame Screw Fix FK-T30 7.5 x L mm
60 mm screw-in depth
X-axis: FRK 4.06 kN
Y-axis: FRK 3.67 kN
UV-resistance of the PVC top layer:
DIN EN 513
(irradiation energy 12 GJ/m² or outdoor weathering over 5 years)		Fastness to weathering and light:
No colour variations occur that exceed grey scale grade 4 according to ISO 105-A03
Waste code:AVV 070213

The information provided in this document corresponds to the information and technical details available to the best of our knowledge. However, this does not constitute a guarantee pursuant to section 443 of the German Civil Code (BGB). Our processing instructions are to be considered only as general guidelines and may differ in the individual case due to the range of possible uses and applications. They do therefore not automatically exempt the user from carrying out their own tests. We reserve the right to make technical modifications and enhancements at any time.

Your product

Your profile system

ELEGANT ABSTRACT 76
EditTo top

Your product

Plinth Thermal Insulation Profile PVC/TK DECEUNINCK for BT 76
EditTo top

Product namePUItem no.

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 30 x 3000 mm

DECEUNINCK for BT 76

1 piece3100001405

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 30 x 4000 mm

DECEUNINCK for BT 76

1 piece3100001414

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 40 x 3000 mm

DECEUNINCK for BT 76

1 piece3100001406

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 40 x 4000 mm

DECEUNINCK for BT 76

1 piece3100001415

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 50 x 3000 mm

DECEUNINCK for BT 76

1 piece3100001407

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 50 x 4000 mm

DECEUNINCK for BT 76

1 piece3100001416

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 80 x 3000 mm

DECEUNINCK for BT 76

1 piece3100001408

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 80 x 4000 mm

DECEUNINCK for BT 76

1 piece3100001417

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 100 x 3000 mm

DECEUNINCK for BT 76

1 piece3100001409

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 100 x 4000 mm

DECEUNINCK for BT 76

1 piece3100001418

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 130 x 3000 mm

DECEUNINCK for BT 76

1 piece3100001410

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 130 x 4000 mm

DECEUNINCK for BT 76

1 piece3100001419

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 150 x 3000 mm

DECEUNINCK for BT 76

1 piece3100001411

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 150 x 4000 mm

DECEUNINCK for BT 76

1 piece3100001420

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 160 x 3000 mm

DECEUNINCK for BT 76

1 piece3100001412

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 160 x 4000 mm

DECEUNINCK for BT 76

1 piece3100001421

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 180 x 3000 mm

DECEUNINCK for BT 76

1 piece3100001413

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 180 x 4000 mm

DECEUNINCK for BT 76

1 piece3100001422

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 200 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007970

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 200 x 4000 mm

DECEUNINCK for BT 76

1 piece3100007976

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 220 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007971

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 220 x 4000 mm

DECEUNINCK for BT 76

1 piece3100007977

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 240 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007972

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 240 x 4000 mm

DECEUNINCK for BT 76

1 piece3100007978

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 260 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007973

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 260 x 4000 mm

DECEUNINCK for BT 76

1 piece3100007979

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 280 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007974

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 280 x 4000 mm

DECEUNINCK for BT 76

1 piece3100007980

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 300 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007975

blaugelb Plinth Thermal Insulation Profile PVC/TK 55 x 300 x 4000 mm

DECEUNINCK for BT 76

1 piece3100007981


blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 30 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007982

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 30 x 4000 mm

DECEUNINCK for BT 76

1 piece3100007997

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 40 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007983

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 40 x 4000 mm

DECEUNINCK for BT 76

1 piece3100007998

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 50 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007984

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 50 x 4000 mm

DECEUNINCK for BT 76

1 piece3100007999

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 80 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007985

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 80 x 4000 mm

DECEUNINCK for BT 76

1 piece3100008000

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 100 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007986

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 100 x 4000 mm

DECEUNINCK for BT 76

1 piece3100008001

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 130 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007987

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 130 x 4000 mm

DECEUNINCK for BT 76

1 piece3100008002

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 150 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007988

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 150 x 4000 mm

DECEUNINCK for BT 76

1 piece3100008003

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 160 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007989

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 160 x 4000 mm

DECEUNINCK for BT 76

1 piece3100008004

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 180 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007990

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 180 x 4000 mm

DECEUNINCK for BT 76

1 piece3100008005

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 200 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007991

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 200 x 4000 mm

DECEUNINCK for BT 76

1 piece3100008006

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 220 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007992

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 220 x 4000 mm

DECEUNINCK for BT 76

1 piece3100008007

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 240 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007993

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 240 x 4000 mm

DECEUNINCK for BT 76

1 piece3100008008

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 260 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007994

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 260 x 4000 mm

DECEUNINCK for BT 76

1 piece3100008009

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 280 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007995

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 280 x 4000 mm

DECEUNINCK for BT 76

1 piece3100008010

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 300 x 3000 mm

DECEUNINCK for BT 76

1 piece3100007996

blaugelb Plinth Thermal Insulation Profile PVC/TK 60 x 300 x 4000 mm

DECEUNINCK for BT 76

1 piece3100008011
